D-Link DWL-8610AP User Manual

Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 444
D-Link UWS User Manual
To use one or more switches as a backup for an AP, use one of the following discovery methods:
• If the AP and any of the peer switches are in the same L2 broadcast domain, L2 Discovery is enabled, and
all the devices use the default VLAN settings, a peer switch will automatically discover the AP if the
primary DWS-4000 Series switch becomes unavailable.
• Configure the IP address of the AP in multiple switches.
• Configure the IP address of up to four switches in the AP while it is in Standalone Mode.
• Configure the DHCP option 43 with the IP addresses of additional switches in the cluster.
Monitoring Status and Statistics
The Status/Statistics folder contains links to the following pages that help you monitor the status and statistics
for your D-Link Unified Switch network:
• Monitoring Status and Statistics
• Managed AP Status
• Associated Client Status/Statistics
• Peer Switch Status
• Radio Resource Measurement Status Information
Wireless Global Status/Statistics
The DWS-4000 Series switch periodically collects information from the APs it manages and from associated
peer switches. The information on the Global page shows status and statistics about the switch and all of the
objects associated with it. You can access the global WLAN statistics by clicking WLAN > Monitoring > Global.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
