Configuring Advanced Settings

D-Link Unified Wired and Wireless Access System

Oct. 2015 Page 608

D-Link UWS User Manual

Configuring the AP Profile Global Settings

From the WLAN > Administration > Advanced Configuration > AP Profile > Access Point Profile Summary

page, you can create, copy, or delete AP profiles. You can create up to 16 AP profiles on the DWS-4000 Series

switch. To create a new profile, enter the name of the profile in the Profile Name field, and then click Add.

Figure 387: AP Profile Global Configuration

Use the Access Point Profile Global Configuration page to configure a variety of global settings for a new or

existing AP profile. When you add a new profile, this page automatically appears and is populated with the

default AP settings.

Table 354: Access Point Profile Global Configuration

Field Description

Profile Name The Access Point profile name you added. Use 0 to 32 characters. Only alphanumeric

characters are allowed. No special characters are allowed.

Hardware Type

Select the hardware type for the APs that use this profile. The hardware type is determined,

in part, by the number of radios the AP supports (single or dual) and the IEEE 802.11 modes

that the radio supports (a/b/g or a/b/g/n/ac). The available options are:

•Any

• DWL-8600AP Dual Radio a/b/g/n

• DWL-8610AP Dual Radio a/b/g/n/ac

• DWL-3600AP Single Radio b/g/n

• DWL-6600AP Dual Radio a/b/g/n

• DWL-2600AP Single Radio b/g/n

• DWL-6610AP Dual Radio a/b/g/n/ac

• DWL-6700AP Outdoor Dual Radio a/b/g/n

• DWL-8710AP Outdoor Dual Radio a/b/g/n/ac
