D-Link DWL-8610AP User Manual

Configuring Spanning Tree Protocol
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 244
D-Link UWS User Manual
• If you make any configuration changes, click Submit to apply the new settings to the switch.
• Click Refresh to update the information on the screen with the most current data.
Table 132: Spanning Tree Switch Configuration/Status Fields
Field Description
Spanning Tree Admin Mode Enables or disables on the switch.
Force Protocol Version Specifies the Force Protocol Version parameter for the switch:
• IEEE 802.1D: Spanning Tree Protocol ()
• IEEE 802.1w: Rapid Spanning Tree Protocol (R)
• IEEE 802.1s: Multiple Spanning Tree Protocol (M)
Configuration Name Name used to identify the configuration currently being used. It may be up to
32 alphanumeric characters.
Configuration Revision Level Number used to identify the configuration currently being used. The values
allowed are between 0 and 65535. The default value is 0.
Configuration Digest Key Number used to identify the configuration currently being used. The digest
key is generated based on the association of VLANs to different instances. To
ensure the digest key is same on two different switches, the mapping of VLAN-
to-instance must be the same.
MST ID Table consisting of the MST instances (including the CST) and the
corresponding VLAN IDs associated with each of them.
VID This table consists of the VLAN identifier (VID) and the corresponding filtering
identifier (FID) associated with each VID.
FID Table consisting of the FIDs and the corresponding VLAN IDs associated with
each of them.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
