D-Link DWL-8610AP User Manual

AP Management
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 590
D-Link UWS User Manual
AP Provisioning
The AP Provisioning feature helps you add new APs to an existing switch cluster. With AP Provisioning, you can
configure the access points with parameters that are needed to connect to the wireless network.
Use AP Provisioning to connect devices to a network enabled for mutual authentication. If a network is not
enabled for mutual authentication then APs can be attached to the network by properly configuring the local
Valid AP database or RADIUS AP database and discovery options. The provisioning feature can optionally be
used on networks not enabled for mutual authentication to simplify AP attachment to the cluster.
AP Provisioning Summary Status
Use the AP Provisioning Summary Status page to view information about all provisioned APs.
Figure 377: AP Provisioning Summary Status
The following table shows the fields available on the AP Provisioning Summary Status page.
Note: The AP Provisioning Summary and Detail pages display data only when the switch is configured
as the Cluster Controller.
Table 346: AP Provisioning Summary Status
Field Description
MAC Address MAC address of the AP
IP Address IP Address of the AP.
Primary IP Address The IP address of the primary provisioned switch as reported by the
AP.
Backup IP Address The IP address of the backup provisioned switch as reported by the AP.
New Primary IP Address Enter the IP address of primary switch to which the AP should try to
connect.
New Backup IP Address Enter the IP address of switch to which the AP should try to connect if
it is unable to connect to the primary switch.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
