D-Link DWL-8610AP User Manual

Locating WLAN Devices
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 664
D-Link UWS User Manual
The following table shows the fields available on the Detailed Client Triangulation Status page.
Command Buttons
The page includes the following button:
• Refresh—Updates the page with the latest information.
Table 384: Detailed Client Triangulation Status
Field Description
MAC Address Selector The menu contains the MAC address of each wireless client listed on
the summary page.
Location Data Indicates whether location data is available for the client.
Device Type Indicates whether the device is a Associated Client or a Detected
Client. If the type of device changes, the change might not be reflected
until the device location is next computed.
Location Computation Status The status of the last iteration of the location computation algorithm:
• Not Executed
• Success
•Failure
Last Successful Computation Amount of time in days, hours, minutes, and seconds that has passed
since the triangulation information was last computed successfully.
Building Number Number that identifies the building where the device is detected. A
value of 0 indicates that no data is available.
Floor Number Number that identifies the floor where the device is detected. A value
of 0 indicates that no data is available.
Detected X Coordinate Identifies the X axis offsets of the client from some arbitrary 0,0 point
on the building floor. A value of 0 indicates that no data is available.
Detected Y Coordinate Identifies the Y axis offsets of the client from some arbitrary 0,0 point
on the building floor. A value of 0 indicates that no data is available.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
