Configuring RIP
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 307
D-Link UWS User Manual
Configuring the RIP Interface
1. Open the RIP Interface Configuration page.
2. Specify the interface for which data is to be configured.
3. Enter data into the fields as needed.
4. To change the Authentication Type, click Configure Authentication to configure different Authentication
Types.
The page refreshes and displays the RIP Interface Authentication Configuration page.
Figure 196: RIP Interface Authentication Configuration
5. Select the type of authentication to use.
If you select Simple or Encrypt as the authentication, the screen refreshes, and additional fields display.
Enter the required information into the new fields.
6. Click Submit to apply the changes to the system and return to the RIP Interface Configuration page.
7. To cancel the authentication configuration and return to the RIP Interface Configuration page, click
Cancel.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
