D-Link DWL-8610AP User Manual

Configuring and Viewing ISDP Information
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 151
D-Link UWS User Manual
Interface Configuration
From the ISDP Interface Configuration page, you can configure the ISDP settings for each interface. To display
the ISDP Cache Table page, click LAN > Administration > ISDP > Interface Configuration in the navigation tree.
Figure 72: ISDP Interface Configuration
The following table describes the fields available on the ISDP Interface Configuration page.
Holdtime Displays the ISDP holdtime for the neighbor.
Capability Displays the ISDP Functional Capabilities for the neighbor.
Platform Displays the ISDP Hardware Platform for the neighbor.
Port ID Displays the ISDP port ID string for the neighbor.
Protocol Version Displays the ISDP Protocol Version for the neighbor.
Last Time Changed Displays when entry was last modified.
Note: If ISDP is enabled on an interface, it must also be enabled globally in order for the interface to
transmit ISDP packets. If the ISDP mode on the ISDP Global Configuration page is disabled, the
interface will not transmit ISDP packets, regardless of the mode configured on the interface.
Table 64: ISDP Interface Configuration
Field Description
Slot/Port Select the interface with the ISDP mode status to configure or view.
ISDP Mode Use this field to enable or disable the Industry Standard Discovery Protocol on
the selected interface.
Table 63: ISDP Cache Table (Cont.)
Field Description

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
