D-Link DWL-8610AP User Manual

RADIUS Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 411
D-Link UWS User Manual
RADIUS Settings
Remote Authorization Dial-In User Service (RADIUS) servers provide additional security for networks. The
RADIUS server maintains a user database, which contains per-user authentication information. RADIUS servers
provide a centralized authentication method for:
• Telnet Access
• Web Access
• Console Access
• Port Access Control (802.1X)
RADIUS Configuration
Use the RADIUS Configuration page to view and configure various settings for the RADIUS servers configured
on the system.
To access the RADIUS Configuration page, click LAN > Security > RADIUS > RADIUS Configuration in the
navigation menu.
Figure 281: RADIUS Configuration
Table 242: RADIUS Configuration Fields
Field Description
Number of Configured
Authentication Servers
The number of RADIUS authentication servers configured on the system. The
value can range from 0 to 32.
Number of Configured
Accounting Servers
The number of RADIUS accounting servers configured on the system. The
value can range from 0 to 32.
Number of Named
Authentication Server Groups
The number of authentication server groups configured on the system. An
authentication server group contains one or more configured authentication
servers that share the same RADIUS server name.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
