D-Link DWL-8610AP User Manual

Authentication List Summary
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 84
D-Link UWS User Manual
Authentication List Summary
Use the Authentication List Summary page to view information about the authentication lists on the system
and which users are associated with each list. The page also displays information about 802.1X port security
users.
To access the Authentication List Summary page, click LAN > Monitoring > Authentication List Summary in the
navigation tree.
Figure 20: Login Session
The Authentication List Summary page has the following fields:
Table 15: Login Fields
Field Description
Login Authentication List Displays all login authentication profiles
Method List Shows the order of the login methods configured for the list. Possible options
are:
• Enable: uses the enable password for authentication.
• Line: uses the Line password for authentication.
• Local:- the user's locally stored ID and password will be used for
authentication
• None: the user is not authenticated
• Radius: the user's ID and password will be authenticated using the RADIUS
server instead of locally
• TACACS+: the user's ID and password will be authenticated using the
TACACS+ server
Remove Removes the authentication profile when checked.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
