D-Link DWL-8610AP User Manual

Erase Startup-config File
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 179
D-Link UWS User Manual
Erase Startup-config File
Use the Erase Startup-config File to erase the startup-configuration file.
To display this page, click Tool > Erase Startup-config File in the navigation menu.
Figure 91: Erase Startup-config File
AutoInstall
The AutoInstall feature enables the configuration of a switch automatically when the device is turned on and,
during the boot process, no configuration file is found in device storage. By communicating with a DHCP
server, AutoInstall obtains an IP address for the switch and an IP address for a TFTP server. AutoInstall
attempts to download a configuration file from the TFTP server and install is on the switch.
After obtaining IP addresses for both the switch and the TFTP server, the AutoInstall feature attempts to
download a host-specific configuration file using the boot file name specified by the DHCP server. If the switch
fails to obtain the file, it will retry indefinitely.
To display this page, click Tool > AutoInstall in the navigation menu.
Figure 92: AutoInstall

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
