D-Link DWL-8610AP User Manual

Configuring MLD Snooping Queriers
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 236
D-Link UWS User Manual
MLD Snooping Querier VLAN Configuration Summary
Use this page to view summary information for MLD Snooping queriers for on VLANs in the network.
To access this page, click Monitoring > MLD Snooping Querier > Querier VLAN Configuration Summary in the
navigation tree.
Figure 141: MLD Snooping Querier VLAN Configuration Summary
• Click Refresh to display the page with the latest information from the router.
Table 125: MLD Snooping Querier VLAN Configuration Summary Fields
Field Description
VLAN ID Specifies the VLAN ID on which MLD Snooping Querier is administratively
enabled.
Querier Election Participate
Mode
Displays the querier election participate mode on the VLAN.
When this mode is disabled, up on seeing a query of the same version in the
VLAN, the snooping querier moves to non-querier state.
When this mode is enabled, the snooping querier participate in querier
election, in which the lowest IP address operates as the querier in that VLAN.
The other querier moves to non-querier state.
Snooping Querier VLAN
Address
Displays the Snooping Querier Address to be used as source IPv6 address in
periodic IGMP queries sent on the specified VLAN.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
