D-Link DWL-8610AP User Manual

SSL/Secure HTTP Configuration
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 379
D-Link UWS User Manual
SSL/Secure HTTP Configuration
Secure HTTP enables the transmission of HTTP over an encrypted Secure Sockets Layer (SSL) or Transport Layer
Security (TLS) connection. When you manage the switch by using a Web interface, secure HTTP can help
ensure that communication between the management system and the switch is protected from
eavesdroppers and man-in-the-middle attacks.
Use the Secure HTTP Configuration page to configure the settings for HTTPS communication between the
management station and the switch.
To display the Secure HTTP Configuration page, click LAN > Security > SSL Configuration in the navigation
menu.
Figure 256: Secure HTTP Configuration
Table 221: Secure HTTP Configuration Fields
Field Description
Admin Mode Enables or Disables the Administrative Mode of Secure HTTP. The currently
configured value is shown when the web page is displayed. The default value
is Disable. You can only download SSL certificates when the HTTPS Admin
mode is disabled.
TLS Version 1 Enables or Disables Transport Layer Security Version 1.0. The currently
configured value is shown when the web page is displayed. The default value
is Enable.
SSL Version 3 Enables or Disables Secure Sockets Layer Version 3.0. The currently configured
value is shown when the web page is displayed. The default value is Enable.
HTTPS Port Sets the HTTPS Port Number. The value must be in the range of 1 to 65535.
Port 443 is the default value. The currently configured value is shown when
the web page is displayed.
HTTPS Session Soft Timeout Sets the inactivity timeout for HTTPS sessions. The value must be in the range
of (1 to 60) minutes. The default value is 5 minutes. The currently configured
value is shown when the web page is displayed.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
