D-Link DWL-8610AP User Manual

Configuring DNS
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 145
D-Link UWS User Manual
Configuring DNS
You can use these pages to configure information about DNS servers the network uses and how the switch/
router operates as a DNS client.
Global Configuration
Use this page to configure global DNS settings and to view DNS client status information.
To access this page, click LAN > Administration > DNS Client > Global Configuration.
Figure 66: DNS Global Configuration
• If you change any settings, click Submit to send the information to the router.
Table 58: DNS Global Configuration Fields
Field Description
Admin Mode Select Enable or Disable from the pulldown menu to set the administrative
status of DNS Client. The default is Disable.
Default Domain Name Enter the default domain name for DNS client messages. The name should be
no longer than 255 characters. When the system is performing a lookup on an
unqualified hostname, this field is provided as the domain name (e.g., if
default domain name is .com and the user enters hotmail, then hotmail is
changed to hotmail.com to resolve the name).
By default, no default domain name is configured in the system.
Retry Number Enter the number of times to retry sending DNS queries. The valid values are
from 0 to 100. The default value is 2.
Response Timeout Enter the number of seconds to allow a DNS server to respond to a request
before issuing a retry. Valid values are 0 to 3600. The default value is 3.
Domain List Enter a domain list to define the domain to use when performing a lookup on
an unqualified hostname. Each name must be no more than 256 characters.
Multiple default domain names can be configured using the default domain-
name list.
If there is no domain list, the default domain name configured is used.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
