TACACS+ Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 434
D-Link UWS User Manual
TACACS+ Settings
D-Link DWS-4000 Series switch provides Terminal Access Controller Access Control System (TACACS+) client
support. TACACS+ provides centralized security for validation of users accessing the device.
TACACS+ provides a centralized user management system, while still retaining consistency with RADIUS and
other authentication processes. TACACS+ provides the following services:
• Authentication: Provides authentication during login and via user names and user-defined passwords.
• Authorization: Performed at login. Once the authentication session is completed, an authorization
session starts using the authenticated user name. The TACACS+ server checks the user privileges.
The TACACS+ protocol ensures network security through encrypted protocol exchanges between the device
and TACACS+ server.
TACACS+ Configuration
The TACACS+ Configuration page contains the TACACS+ settings for communication between the switch and
the TACACS+ server you configure.
To display the TACACS+ Configuration page, click LAN > SecurityTACACS+ > Configuration in the navigation
menu.
Figure 301: TACACS+ Configuration
• If you make any changes to the page, click Submit to apply the new settings to the system.
Table 256: TACACS+ Configuration Fields
Field Description
Key String Specifies the authentication and encryption key for TACACS+ communications
between the device and the TACACS+ server. The valid range is 0-128
characters. The key must match the key configured on the TACACS+ server.
Connection Timeout The maximum number of seconds allowed to establish a TCP connection
between the device and the TACACS+ server.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
