D-Link DWL-8610AP User Manual

Basic Setup
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 574
D-Link UWS User Manual
Local OUI Database Summary
To help identify AP and Wireless Client adapter manufacturers detected in the wireless network, the wireless
switch contains a database of registered Organizationally Unique Identifiers (OUIs). This is a read-only list with
over 10,000 registrations. From the Local OUI Database Summary page, you can enter up to 64 user-defined
OUIs. The local list is searched first, so the same OUI can be located in the local list as well as the read-only list.
Figure 367: Local OUI Database Summary
After you enter the OUI value and description, click Add to add the OUI to the local database.
Command Buttons
The page includes the following buttons:
• Add—Adds the OUI value and description information to the local OUI database.
• Delete—Deletes any selected OUI entries from the local OUI database. This button is available if the check
box next to at least one OUI entry is selected.
• Delete All—Deletes all manually-added entries from the local OUI database.
• Refresh—Updates the page with the latest information.
Table 336: Local OUI Database Summary
Field Description
OUI Value Enter the OUI that represents the company ID in the format XX:XX:XX where XX is a
hexadecimal number between 00 and FF. The first three bytes of the MAC address
represents the company ID assignment.
Note: The first byte of the OUI must have the least significant bit set to 0. For
example 02:FF:FF is a valid OUI, but 03:FF:FF is not.
OUI Description Enter the organization name associated with the OUI. The name can be up to 32
alphanumeric characters.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
