D-Link DWL-8610AP User Manual

Managing the DHCP Server
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 138
D-Link UWS User Manual
Bindings Information
Use the DHCP Server Bindings Information page to view information about the IP address bindings in the
DHCP server database.
To access the DHCP Server Bindings Information page, click LAN > Monitoring > DHCP Server Summary >
Binding Information in the navigation tree.
Figure 60: Bindings Information
• If you change any settings, click Submit to apply the changes to the system.
Table 52: Bindings Information Fields
Field Description
DHCP Binding Select the bindings to display:
• All Bindings: Show all bindings.
• Specific Binding: Show a specific binding. When you select this option, the
screen refreshes, and the Binding IP Address field appears.
Binding IP Address Specify the IP address for which you want to view binding information. This
field is only available if you select Specific Binding from the DHCP Binding
field.
IP Address Displays the client IP address.
Hardware Address Displays the client MAC address.
Lease Time Left Shows the remaining time left in the lease in Days, Hours and Minutes
dd:hh:mm format.
Pool Allocation Type Shows the type of binding, which is dynamic or manual.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
