Configuring Differentiated Services
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 353
D-Link UWS User Manual
Click Refresh to update the information on the screen.
Table 210: Service Detailed Statistics Fields
Field Description
Counter Mode
Selector
Selects the format of the displayed counter values, which must be either Octets or Packets.
The default is Octets.
Interface List of all valid slot number and port number combinations in the system that have a
DiffServ policy currently attached in the In direction.
Direction Selects the direction of packets for which service statistics are to display. Only shows the
direction(s) for which a DiffServ policy is currently attached.
Policy Name Displays the policy currently attached to the selected interface and direction.
Operational
Status
Displays the operational status of the policy currently attached to the specified interface
and direction. The value is either Up or Down.
Member Classes List of all DiffServ classes currently defined as members of the selected Policy Name.
Choose one member class name at a time to display its statistics. If no class is associated
with the chosen policy, then nothing will be populated in the list.
Offered Packets/
Octets
Displays the count of the packets/octets offered to this class instance before the defined
DiffServ treatment is applied.
Discarded
Packets/Octets
Displays the count of packets/octets discarded for this class instance for any reason due to
DiffServ treatment of the traffic class.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
