D-Link DWL-8610AP User Manual

User Accounts
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 80
D-Link UWS User Manual
Adding a User Account
Use the following procedures to add a user account. The system supports one Read/Write user and five Read
Only users.
1. From the User menu, select Create.
The screen refreshes.
2. Enter a username and password for the new user, then re-enter the password in the Confirm Password
field.
3. Click Submit to update the switch with the values on this screen.
If you want the switch to retain the new values across a power cycle, you must perform a save.
Changing User Account Information
You cannot add or delete the Read/Write user, but you can change the username and password. To change
the password for an existing account or to overwrite the username on an existing account, use the following
procedures.
1. From the User menu, select the user to change.
The screen refreshes.
2. To alter the username or, delete the existing name in the Username field and enter the new username.
To change the password, delete any asterisks (*) in the Password and Confirm Password fields, and then
enter and confirm the new password.
3. Click Submit to update the switch with the values on this screen.
If you want the switch to retain the new values across a power cycle, you must perform a save.
Deleting a User Account
Use the following procedures to delete any of the Read Only user accounts.
1. From the User menu, select the user to delete.
The screen refreshes.
2. Click Delete to delete the user.
This button is only visible when you have selected a user account with 'Read Only' access. You cannot
delete the 'Read/Write' user.
If you want the switch to retain the new values across a power cycle, you must perform a save.
Encryption Key If you selected DES in the Encryption Protocol field enter the SNMPv3
Encryption Key here. Otherwise this field is ignored. Valid keys are 0 to 15
characters long. The Apply check box must be selected in order to change the
Encryption Protocol and Encryption Key.
Table 13: User Accounts Fields (Cont.)
Field Description

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
