D-Link DWL-8610AP User Manual

Managing the DHCP Server
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 136
D-Link UWS User Manual
Pool Options
Use the Pool Options page to configure DHCP options that the DHCP server can pass to the client. For more
information about DHCP options, see RFC 2132.
To access the Pool Options page, click LAN > Administration > DHCP Server > Pool Options in the navigation
menu.
If no DHCP pools exist, the Pool Options page does not display the fields shown in Figure 58.
Figure 58: Pool Options
If any DHCP pools are configured on the system, the Pool Options page contains the following fields:
To delete an option code for the selected Pool, enter the option code in the folder and click Delete. This button
is not visible to a user with read-only permission.DHCP Server Summary
Table 50: Pool Options Fields
Field Description
Pool Name Select the DHCP pool to with the options you want to view or configure.
Option Code Displays the DHCP option code configured for the selected Pool.
ASCII Value Specifies the Option ASCII Value for the selected pool
Hex Value Specifies the Option Hex Value for the selected pool.
IP Address Value Specifies the Option IP Address Value for the selected pool.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
