Command Buttons
The page includes the following button:
• Refresh—Updates the page with the latest information.
Viewing Distributed Tunneling Statistics
The distributed tunneling statistics show information about the number of packets and bytes transmitted and
received by clients that use L2 distributed tunnels on an access point managed by the switch.
Use the menu above the table to select the AP with the settings to view. The AP is identified by its MAC address
and location.
Table 284 describes the fields you see on the Distributed Tunneling Statistics page for the managed access
point statistics.
Client Association Failures Number of clients that have been denied association to the VAP.
Client Authentication Failures Number of clients that have failed authentication to the VAP.
TSPEC Statistics (Voice and Video)
Total TSPEC Packets Received The number of TSPEC packets sent from the wireless client to the AP on
the VAP.
Total TSPEC Packets Transmitted The number of TSPEC packets sent from the AP to the wireless client on
the VAP.
Total TSPEC Bytes Received The number of TSPEC bytes sent from the wireless client to the AP on the
VAP.
Total TSPEC Bytes Transmitted The number of TSPEC bytes sent from the AP to the wireless client on the
VAP.
Table 284: Managed Access Point Distributed Tunneling Statistics
Field Description
Bytes Transmitted Total bytes transmitted via all distributed tunnels by the AP.
Bytes Received Total bytes received via all distributed tunnels by the AP.
Multicast Packets Transmitted Total multicast packets transmitted via all distributed tunnels by the AP.
Multicast Packets Received Total multicast packets received via all distributed tunnels by the AP.
Packets Transmitted Total packets transmitted via all distributed tunnels by the AP.
Packets Received Total packets received via all distributed tunnels by the AP.
Total Roamed Clients of AP Number of Clients that used this AP for distributed tunneling. The count
include clients that roamed away and roamed to this AP.
Roamed Clients Idle Timed Out Number of Clients that roamed away from this AP and were timed out
due to not sending traffic on the tunnel.
Table 283: Managed Access Point VAP Statistics
Field Description

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
