Locating WLAN Devices
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 658
D-Link UWS User Manual
On-Demand Location Trigger Floor Status
Use the On-Demand Location Trigger Floor Status page to view the results of the most recent On-Demand
Location procedure for each floor. The page can display entries for each floor, even if the device is not detected
on the floor. If a building or floor was not included in the On-Demand search parameters, no data is reported
for the floor.
Figure 414: On-Demand Location Trigger Floor Status
The following table shows the fields available on the On-Demand Location Trigger Floor Status page.
Table 380: On-Demand Location Trigger Floor Status
Field Description
Building Number Number that identifies the building that was searched for the device.
Floor Number Number that identifies the floor of the building that was searched for the
device.
Device Found Indicates whether the device was found on the selected floor.
Number of Detecting APs Number of managed APs that detected the device.
Solution Type Indicates whether the probability map is a circle around the managed AP
(Circle), or the solution is an X,Y coordinate (Point Solution).
X-Coordinate Identifies the X axis offset of the managed AP from some arbitrary 0,0 point on
the building floor.
Y-Coordinate Identifies the Y axis offset of the managed AP from some arbitrary 0,0 point on
the building floor.
Circle Radius For the Circle solution this parameter represents the radius from the X,Y
coordinate where the device is most likely to be located. For the Point solution
this value is not applicable and is set to 0.
Sigma The standard deviation for the location. The parameter is applicable to Circle
and Point solutions. For the Circle solution the Sigma represents the offset from
"Circle Radius". For the Point solution the sigma represents the radius from the
X,Y coordinate.
