D-Link DWL-8610AP User Manual

RADIUS Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 415
D-Link UWS User Manual
Use the buttons at the bottom of the page to perform the following actions:
• If you make changes to the page, click Submit to apply the changes to the system.
• To delete a configured RADIUS authentication server, select the IP address of the server from the RADIUS
Server Host Address menu, and then click Remove.
• Click Refresh to update the page with the most current information.
Viewing Named Server Status Information
The RADIUS Named Server Status page shows summary information about the RADIUS servers configured on
the system.
Figure 284: Named Server Status
Click Refresh to update the page with the most current information.
Table 244: RADIUS Server Configuration Fields
Field Description
Current An asterisk (*) in the column Indicates that the server is the current server for
the authentication server group. If no asterisk is present, the server is a
backup server.
If more than one RADIUS server is configured with the same name, the switch
selects one of the servers to be the current server from the group of servers
with the same name.
When the switch sends a RADIUS request to the named server, the request is
directed to the server selected as the current server. Initially the primary
server is selected as the current server. If the primary server fails, one of the
other servers becomes the current server.
RADIUS Server Host Address Shows the IP address of the RADIUS server.
RADIUS Server Name Shows the RADIUS server name.
Multiple RADIUS servers can have the same name. In this case, RADIUS clients
can use RADIUS servers with the same name as backups for each other.
Port Number Identifies the authentication port the server uses to verify the RADIUS server
authentication. The port is a UDP port.
Server Type Shows whether the server is a Primary or Secondary server.
Secret Configured Indicates whether the shared secret for this server has been configured.
Message Authenticator Shows whether the message authenticator attribute for the selected server is
enabled or disabled.
