D-Link DWL-8610AP User Manual

Save All Applied Changes
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 171
D-Link UWS User Manual
Save All Applied Changes
When you click Submit, the changes are applied to the system and saved in the running configuration file.
However, these changes are not saved to non-volatile memory and will be lost if the system resets. Use the
Save All Applied Changes page to make the changes you submit persist across a system reset.
To access the Save All Applied Changes page, click Tool > Save Changes in the navigation tree.
Figure 85: Save All Applied Changes
Click Save to save all changes applied to the system to NVRAM so that they are retained if the system reboots.
Download File To Switch (TFTP)
Use the Download File to Switch page to download the image file, the configuration files, CLI banner file, and
SSH or SSL files from a TFTP server to the switch.
You can also download files via HTTP. See “HTTP File Download” on page 174 for more information.
To access the Download File to Switch page, click Tool > Download File in the navigation tree.
Figure 86: Download File to Switch

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
