Configuring Port Security
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 375
D-Link UWS User Manual
• If you make any changes to the page, click Submit to apply the new settings to the system.
Table 217: Port Security Interface Configuration Fields
Field Description
Interface Select the physical interface or the LAG on which to configure port security
information.
Port Security Determines whether port security is enabled. The default mode is Disable.
• Enable: Locks the port so that only packets with allowable source MAC
addresses can be forwarded. All other packets are discarded.
• Disable: The port is not locked, so no port security restrictions are applied.
Maximum Number of
Dynamically Learned MAC
Addresses Allowed
Sets the maximum number of dynamically learned MAC addresses on the
selected interface. Once the limit is reached, no more addresses are learned
on the port. Any packets with source MAC addresses that were not already
learned are discarded. You can effectively disable dynamic locking by setting
the number of allowable dynamic entries to zero.
Maximum Number of
Statically Locked MAC
Addresses Allowed
Sets the maximum number of statically locked MAC addresses on the selected
interface.
Add a Static MAC Address Adds a MAC address to the list of statically locked MAC addresses for the
selected interface. Only packets with an allowable source MAC address can be
forwarded.
VLAN ID Adds a corresponding VLAN ID for the MAC Address being added to the list of
statically locked MAC addresses for the selected interface.
Enable Violation Traps Enables or disables the sending of new violation traps designating when a
packet with a disallowed MAC address is received on a locked port. Value is No
by default.
Convert dynamically learned
address to static locked
When you click Move, all the dynamically learned entries on this interface are
added to the static MAC address list for this interface. After moving them, you
can view them in the Port Security Static page.
