D-Link DWL-8610AP User Manual

Using System Tools
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 169
D-Link UWS User Manual
Section 3: Using System Tools
The Tools menu contains links to the following Web pages that help you perform switch maintenance:
• “Reset Configuration to Defaults”
• “Reset Passwords to Defaults”
• “System Reset”
• “Save All Applied Changes”
• “Download File To Switch (TFTP)”
• “HTTP File Download”
• “Upload File From Switch (TFTP)”
• “Multiple Image Service”
• “Erase Startup-config File”
• “AutoInstall”
Reset Configuration to Defaults
Use the Reset Configuration to Defaults page to reset the system configuration to the factory default values.
To access the Reset Configuration to Defaults page, click Tool > Reset Configuration in the navigation tree.
Figure 82: Reset Configuration to Defaults
• Click Reset to restore the factory default settings. The screen refreshes and asks you to confirm the reset.
Click Reset again to complete the action.
Note: By default, the switch IP address is 10.90.90.90 and the DHCP client is disabled. When you reset
the system to its default values, the network IP address resets to 10.90.90.90. For information about
configuring network information, see “Connecting the Switch to the Network” on page 43.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
