D-Link DWL-8610AP User Manual

Viewing System Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 159
D-Link UWS User Manual
Table 70: Switch Detailed Statistics Fields
Field Description
fIndex This object indicates the ifIndex of the interface table entry associated with
the processor of this switch.
Octets Received The total number of octets of data received by the processor (excluding
framing bits but including FCS octets).
Unicast Packets Received The number of subnetwork-unicast packets delivered to a higher-layer
protocol.
Multicast Packets Received The total number of packets received that were directed to a multicast
address. Note that this number does not include packets directed to the
broadcast address.
Broadcast Packets Received The total number of packets received that were directed to the broadcast
address. Note that this does not include multicast packets.
Receive Packets Discarded The number of inbound packets which were chosen to be discarded even
though no errors had been detected to prevent their being deliverable to a
higher-layer protocol. A possible reason for discarding a packet could be to
free up buffer space.
Octets Transmitted The total number of octets transmitted out of the interface, including framing
characters.
Packets Transmitted Without
Errors
The total number of packets transmitted out of the interface.
Unicast Packets Transmitted The total number of packets that higher-level protocols requested be
transmitted to a subnetwork-unicast address, including those that were
discarded or not sent.
Multicast Packets
Transmitted
The total number of packets that higher-level protocols requested be
transmitted to a Multicast address, including those that were discarded or not
sent.
Broadcast Packets
Transmitted
The total number of packets that higher-level protocols requested be
transmitted to the Broadcast address, including those that were discarded or
not sent.
Transmit Packets Discarded The number of outbound packets which were chosen to be discarded even
though no errors had been detected to prevent their being deliverable to a
higher-layer protocol. A possible reason for discarding a packet could be to
free up buffer space.
Most Address Entries Ever
Used
The highest number of Forwarding Database Address Table entries that have
been learned by this switch since the most recent reboot.
Address Entries in Use The number of Learned and static entries in the Forwarding Database Address
Table for this switch.
Maximum VLAN Entries The maximum number of Virtual LANs (VLANs) allowed on this switch.
Most VLAN Entries Ever Used The largest number of VLANs that have been active on this switch since the
last reboot.
Static VLAN Entries The number of presently active VLAN entries on this switch that have been
created statically.
Dynamic VLAN Entries The number of presently active VLAN entries on this switch that have been
created by GVRP registration.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
