D-Link DWL-8610AP User Manual

Configuring DNS
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 148
D-Link UWS User Manual
DNS Host Name IP Mapping Summary
Use this page to configure static and dynamic DNS host names for hosts on the network. The host names are
associated with IPv4 or IPv6 addresses on the network, which are assigned to particular hosts.
To access this page, click LAN > Monitoring > DNS Server > Host Name IP Mapping Summary in the navigation
tree.
Figure 69: DNS Host Name IP Mapping Summary
• Click Add Static Entry to load the Host Name IP Mapping Configuration page in order to configure the
Host Name IP Mapping entries.
• Click Submit to apply the new configuration and cause the change to take effect immediately. These
changes will not be retained across a power cycle unless a Save is performed.
• Click Clear Dynamic Entries to remove all Host Name IP Mapping entries. A confirmation prompt will be
displayed. Click the button to confirm removal and the Host Name IP Mapping dynamic entries are
cleared.
• Click Refresh to refresh the page with the most current data from the switch.
Table 61: DNS Host Name IP Mapping Summary Fields
Field Description
DNS Static Entries
Host Name The host name of the static entry.
Inet Address The IP4 or IPv6 address of the static entry.
Remove Select to remove a Host Name IP Mapping entry from the Host Name IP
Mapping list.
DNS Dynamic Entries
Host Name The host name of the dynamic entry.
Total The total time of the dynamic entry.
Elapsed The elapsed time of the dynamic entry.
Type The type of the dynamic entry.
Addresses The IP4 or IPv6 address of the dynamic entry.
Remove Select to remove a Host Name IP Mapping entry from the Host Name IP
Mapping list.

D-Link DWL-8610AP Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.497, 4.9 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Wi-Fi data rate (max)	1750 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Flash memory	64 MB
Internal memory	512 MB
Internal	No
Certification	CE, FCC, IC
Product color	Gray
Ethernet LAN (RJ-45) ports	2
Antennas quantity	6
Antenna gain level (max)	6.5 dBi
Power supply type	PoE, DC
Power consumption (typical)	14 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	265 mm
Package width	238 mm
Package height	112 mm
Package weight	1160 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1955 mm
Pallet gross weight (air)	385580 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	280 mm
Shipping (inner) case height	260 mm
Shipping (inner) case length	585 mm
Shipping (inner) case weight	8740 g
Shipping (inner) case net weight	5800 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	171 mm
Width	198 mm
Height	40 mm
Weight	240 g
