Configuring Port Security
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 377
D-Link UWS User Manual
Port Security Dynamic
Use the Port Security Dynamic page to view a table with the dynamically learned MAC addresses on an
interface. With dynamic locking, MAC addresses are learned on a “first arrival” basis. You specify how many
addresses can be learned on the locked port.
To access the Port Security Dynamic page, click LAN > Monitoring > Port Security > Port Security Dynamic in
the navigation tree.
Figure 254: Port Security Dynamic
Table 219: Port Security Dynamic Fields
Field Description
Interface Select the physical interface or the LAG on which to view the dynamically
learned MAC addresses.
MAC Address This column lists the dynamically learned MAC addresses, if any, on the
selected port.
VLAN ID Displays the VLAN ID corresponding to the dynamically learned MAC address.
