2008T Troubleshooting Guide
P/N 490292 Rev. A
T- 7.6.6 ADJUST ‘SLOW FLOW’ MONITOR REFERENCE
a) ‘Sharply’ press ‘Enter’ to turn [Monitor Reference] pale yellow / white!
b) Adjust [Monitor Reference] to match the meter’s highest reading (i.e. between 36.9 and 37.1° C).
c) CAREFUL HERE! Sharply ‘Enter’ TWICE to turn [Monitor Reference] GRAY!
d) Does the GRAY [Monitor Reference] data box read between 36.4 and 37.6° C?
Yes The data box is between 36.4 and 37.6° C! This completes the calibration HOWEVER, if you
started out troubleshooting a “TEMP OVER 95 DEGREES” in Heat Disinfect proceed to
page 265, procedure number T- 1.5.1. If not, return to Dialysis Program.
No The data box IS NOT between 36.4 and 37.8! With the machine off, swap in the listed
components (see COMPONENT LIST below), one at a time, with known good, in between
returning to (ABOVE) procedure number T- 7.2.1 (page 323) to test each new component.
COMPONENT LIST: 1) NTC #3
1
; 2) Functional Board.
1
To LOCATE NTC #3 refer to Figure 42 (page 236)
LEFT BLANK INTENTIONALLY
