2008T Troubleshooting Guide
P/N 490292 Rev. A
F- 1.0.8.11 CYCLES TO LESS THAN 11 PSI
Figure right, TWO (2) possible scenarios:
1) IF (and ONLY if) NOT equipped with a
bibag Connector: Proceed to page 137,
procedure number F- 18.0.0.
2) IF equipped with a bibag Connector: See
parts A AND B below:
A) Per the Figure below, clamp the tubing attached at the top of Valve #101.
B) Does Loading Pressure continue to drop below 11 psi?
Yes Continues to drop below 11 psi! Proceed to
page 137, procedure number
F- 18.0.0.
No Does NOT drop below 11 psi now! See procedure number F- 1.0.8.2 (page 35).
F- 1.0.8.2 PRESSURE DOES NOT DROP BELOW 11 PSI
TWO (2) possible scenarios:
1) IF (and ONLY if) PEAKS to between 23 and 27 psi: Leaving the clamp in place for now, proceed to
page 38, procedure number F- 2.0.0.
2) IF PEAKS to between 15 and 22 psi: Return to
page 34, procedure number F- 1.0.8.
