February 2013
5-66
ColorQube® 9303 Family
PL 31.11
Parts Lists
PL 31.11 Maintenance/Installation/
Removal Kits (2 of 3)
Item Part Description
1 604K54580 OCT centre registration kit
2 604K41411 LCSS Front cover Kit
3 604K35700 Stapler kit (XE)
– 604K35710 Stapler kit (USSG/XCL)
4 – Wireless network adapter kit
(NOTE 3)
5 497K04690 Tri-folder install kit (complete)
6 604K73060 LCSS paddle shaft assembly kit
7 604K54870 Registration/Pre-heat pump kit
(Contains 2 air pumps)(W/O TAG
018)
8 897E31770 French/Canadian UI overlay kit
9 604K67940 Drum pulley removal kit
10 604K73400 HVF ejector assembly safety cover
kit
11 604K73340 Drum repair kit
12 604K67130 Tray 3 guide kit
13 604K61410 Wave amp cable and clip kit (Type
A)
14 604K60701 DADH mylar guide kit
15 604K67230 LCSS traverse kit
16 – Smartcard enablement kit (Not
spared)
17 604K62080 DADH sensor replacement kit
18 604K83720 LCSS diverter gate assembly
spares kit
19 604K54990 Nip A replacement kit (Contains 2
belts and 2 Nip A roller assemblies)
20 130K75140 LCSS stapler edge registration
sensor kit
21 604K54320 Front transfix linkage and gear kit
22 604K54330 Rear transfix linkage and gear kit
23 604K54100 Hardware kit (see NOTE 2)
24 498K19200 20 Amp adapter kit
25 – Not used
26 604K55480 Feed roll kit
27 – Install NAT kit (XE) (Not spared)
28 – Install NAT kit (USSG/XCL) (Not
spared)
29 604K61420 Video cable and clip kit (Type A)
30 604K61370 3TM Cable kit
31 604K61710 Tray 3 kit
32 604K61640 Silicon oil removal kit
33 650K33140 UI overlay kit (English)
NOTE: 1: 498K part numbers should not be ordered by the
CSE. 498K part numbers are customer install kits and are
shown for reference only.
NOTE: 2: Refer to GP 24 for contents of the hardware kit.
NOTE: 3. Part number not available at time of publication.
