Xerox ColorQube 9303 Series Service Manual

February 2013
1-7
ColorQube® 9303 Family
SCP 4
Service Call Procedures
SCP 4 Subsystem Maintenance
Use SCP 4 Subsystem Maintenance to maintain the machine.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 14. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Go to the correct procedure:
• HFSI
• Lubrication
• How to Clean the Machine
HFSI
The High Frequency Service Items are shown in Table 1 HFSI replacement and Table 2 HFSI
cleaning. To change HFSI settings, refer to dC135 CRU / HFSI Status.
Lubrication
To lubricate the machine, refer to ADJ 4.1 Machine Lubrication.
How to Clean the Machine
To clean the machine, refer to GP 27 Cleaning Procedure.
Table 1 HFSI replacement
Item Component Description
The
recommended
life for new
component
installation
Parts list
reference
Tray 1 feed Feed rolls All sheets fed from tray 1
after last HFSI reset
600k feeds PL 81.25 Item 6
PL 81.25 Item 9
PL 81.25 Item 11
Tray 2 feed Feed rolls All sheets fed from tray 2
after last HFSI reset
600k feeds PL 81.26 Item 6
PL 81.26 Item 9
PL 81.26 Item 11
Tray 3 feed Feed rolls All sheets fed from tray 3
after last HFSI reset
600k feeds PL 81.30 Item 6
PL 81.30 Item 9
PL 81.30 Item 11
Bypass tray 4
feeds
Bypass tray
feed rolls
The total bypass tray 4
feeds after the last HFSI
reset
600k feeds PL 74.10 Item 7
PL 74.10 Item 13
PL 74.10 Item 14
Tray 5 feeds Tray 5 feed
rolls
All sheets fed from tray 5
after last HFSI reset
600k feeds PL 81.45 Item 2
Inserter tray 6 Inserter feed
rolls
Total Inserter feeds 80k feeds PL 12.310 Item 1
Transfix strip-
per
Transfix strip-
per assembly
All sheets fed after last
HFSI reset
460k feeds PL 10.20 Item 14
Table 2 HFSI cleaning
Item Component Description
The
recommended
cleaning
frequency
Parts list
reference
Drum fan
shroud
Drum fan
shroud
All sheets fed after last
HFSI reset
500k feeds PL 94.20 Item 5
Upper JL baf-
fle
Upper baffle All sheets fed after last
HFSI reset
400k feeds PL 10.10 Item 9
