Xerox ColorQube 9303 Series Service Manual

February 2013
6-99
ColorQube® 9303 Family
GP 34, GP 35
General Procedures/Information
Figure 3 DMO Sold
GP 35 Copy and Print Speeds
Purpose
To define copy and print speeds for all models.
Procedure
Go to the relevant section. Also, refer to General Notes:
• Print Modes
• Copy Speeds
• Print Speeds
General Notes
1. For systems with weak or missing jets and jet substitution switched on, the productivity
figures will be reduced as the system performs additional image passes to compensate
for the missing jet.
2. Halve all print speeds for SEF media, except where the SEF media is less than 8.5 inches
in length and greater than or equal to 8.27 inches not including envelopes.
3. In Standard mode the print rate will be reduced by up to 50% as the percent fill of any
colour increases above 55%.
4. If photographic original subtype is selected in Photo and Text original type then the
enhanced output quality is selected. Refer to Table 1.
5. All user selected black and white output modes are always accounted as black and white
pages. Refer to Table 3.
6. ColorQube 9301 standard colour: Productivity may be reduced for jobs greater than 1200
pages with continuous area coverage greater than 190% for configurations with a HVF.
7. ColorQube 9302 standard colour: Productivity may be reduced for jobs greater than 1200
pages with continuous area coverage greater than 150% for configurations without a HVF.
8. ColorQube 9303 standard colour: Productivity may be reduced for jobs greater than 1200
pages with continuous area coverage greater than 110% for configurations with a HVF.
9. For modes that run faster than standard colour, there may be some reduction in productiv-
ity as area coverage increases.
Print Modes
Refer Table 1.
2 Dots
Table 1 Print Modes
Fast Colour Postscript
Print quality output is faster, less dense and at a lower resolution
than Standard Mode.
Standard Postscript
Print quality output is faster, less dense and at a lower resolution
than Enhanced Mode.
Enhanced (default) Postscript and PCL
Print output quality is the highest speed possible for widely accept-
able print quality.
High Resolution / Photo Postscript and PCL
Print output quality is the highest quality output
