Network structures
6.1 VLAN
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
174 Configuration Manual, 11/2015, C79000-G8976-C252-10
The entries of the subnet VLAN table are displayed.
This command shows the specific information for all or a selected VLAN.
You are in the User EXEC mode or in the Privileged EXEC mode.
The command prompt is as follows:
cli> or cli#
Call up the command with the following parameters:
show vlan[brief|id<vlan-range>|summary]
The parameters have the following meaning:
Shows brief information about all
-
Keyword for a VLAN or VLAN range -
Number of the addressed VLAN or
1 ... 4094
Shows a summary of the VLANs
If you do not select any parameter from the parameter list, the entries of all available
interfaces are displayed.
The information for the selected VLAN is displayed.
show vlan device info
Description
This command shows all the global information that is valid for all VLANs.
