Network structures
6.3 Spanning Tree
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
214 Configuration Manual, 11/2015, C79000-G8976-C252-10
Result
The settings for the active ports of the spanning tree function are displayed.
6.3.1.4
show spanning-tree bridge
Description
This command shows the settings of the spanning tree function of the bridge.
Requirement
You are in the User EXEC mode or in the Privileged EXEC mode.
The command prompt is as follows:
cli> or cli#
Syntax
Call up the command with the following parameters:
show spanning-tree bridge
[{address|forward-time|hello-time|id|max-age|protocol|priority|detail}]
The parameters have the following meaning:
Parameter
Description
address
Shows the MAC address of the bridge
forward-time
Shows the time that the bridge is in the listening mode when changing from
the blocking mode to the learning mode
hello-time
Shows the time after which the bridge sends configuration frames (BPDUs)
id
Shows the ID of the bridge
max-age
Shows the maximum age of the data packet after which it is deleted
protocol
Shows the protocol used
priority
Shows the priority of the bridge
detail
Shows detailed information about the spanning tree settings of the interface
Result
The settings for the spanning tree function of the bridge are displayed.
6.3.1.5
show spanning-tree detail
Description
This command shows the detailed settings of the spanning tree function.
