Siemens SCALANCE XR-500 Configuration Manual

Network structures
6.1 VLAN
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
190 Configuration Manual, 11/2015, C79000-G8976-C252-10
Result
The setting is reset to the default value.
Further notes
You configure the setting with the switchport acceptable-frame-type command.
You can display the status of this function and other information with the
show vlan port
config
command.
6.1.3.5
switchport access vlan
Description
With this command, you assign an VLAN to an interface and configure the port VLAN
identifier (PVID) for it.
Requirement
You are in the Interface configuration mode.
The command prompt is as follows:
cli(config-if-$$$)#
Syntax
Call up the command with the following parameters:
switchport access vlan <vlan-id(1-4094)>
The parameter has the following meaning:
Parameter
Description
Range of values / note
vlan-id
Number of the addressed VLAN
1 ... 4094
Result
The Interface is added to the VLAN as an untagged port and the corresponding VLAN ID is
set.
Further notes
You can reset the setting to the default with the no switchport access vlan command.
You display the setting and other information with the
show vlan port config command.

Siemens SCALANCE XR-500 Specifications

General

Product function / VLAN	Yes
Port Types	Ethernet
Operating voltage / rated value	24 V DC
Supply voltage / 1	24 V DC
Type of voltage / 1 / of the supply voltage	DC
Operating Temperature	-40 ... 70 °C
Mounting Type	Wall mounting, DIN rail mounting
Mounting	DIN rail, wall mounting
Protocol Support	SNMP
Redundancy	Yes
Certifications	UL, CE, FCC, ATEX, IECEx
