Siemens SCALANCE XR-500 Configuration Manual

Network structures
6.3 Spanning Tree
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
212 Configuration Manual, 11/2015, C79000-G8976-C252-10
Syntax
Call up the command with the following parameters:
show spanning-tree [{summary|blockedports|pathcost method}]
The parameters have the following meaning:
Parameter
Description
summary
Shows a summary
blockedports
Shows the blocked ports
pathcost method
Shows whether 16-bit (short) or 32 bit (long) values are used in the calcula-
tion
Result
The settings for the spanning tree function are displayed.
Further notes
You can show further settings for special aspects of the Spanning Tree Protocol with the
following commands:
●
show spanning-tree active
●
show spanning-tree bridge
●
show spanning-tree detail
●
show spanning-tree interface
●
show spanning-tree root
●
show spanning-tree mst
6.3.1.2
show spanning-tree mst
Description
This command shows various settings of the spanning tree configuration specific to a
Common Internal Spanning Tree (CIST) instance or a selected instance of the Multiple
Spanning Tree Protocol.
Requirement
You are in the User EXEC mode or in the Privileged EXEC mode.
The command prompt is as follows:
cli> or cli#
