Network structures
6.1 VLAN
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
202 Configuration Manual, 11/2015, C79000-G8976-C252-10
It is possible to remove individual ports from a VLAN configuration without needing to rewrite
the entire configuration (in contrast to creating ports because it is not possible to add
individual ports later).
You display details of the function with the
show vlan command.
You configure the setting with the
ports command.
With this command, you assign a name to the VLAN.
You are in the VLAN Configuration mode.
The command prompt is as follows:
cli(config-vlan-$$$)#
Call up the command with the following parameters:
name <vlan-name>
The parameter has the following meaning:
Name that will be assigned to the
max. 32 characters
The VLAN is assigned a name.
You delete name assignment for a VLAN with the no name command.
With this command, you delete the name assignment for a VLAN.
