Layer 3 functions
9.4 VRRPv2 (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
559
Call up the command with the following parameters:
vrrp <vrid(1-255)> group shutdown
The parameter has the following meaning:
All IPv4 addresses of the group are removed.
You configure a VRRP interface with the interface command.
You display the IPv4 addresses with the
show vrrp interface - vrid command.
With this command, you specify that a router with higher priority can take over the master
role from a router with lower priority.
Note
This command is available only with layer 3.
● An IPv4 address is assigned to the virtual router.
● You are in the VRRP Interface configuration mode
.The command prompt is:
cli(config-vrrp-if)#
