Diagnostics
12.4 Port Mirroring
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
794 Configuration Manual, 11/2015, C79000-G8976-C252-10
● loopd is enabled
● You are in the Interface configuration mode.
The command prompt is:
cli(config-if-$$$)#
Call the command without parameters:
no loopd reaction remote
"no action" is activated for the loop reaction remote function.
"disable" is the default after enabling loop detection.
You enable the "disable" setting with the loopd reaction remote command.
You can display the status of this function and other information with the
show loopd
command.
Note
It cannot be guaranteed when mirroring the data traffic that all packets are mirrored.
With the port mirroring function, you copy the data stream of one or more ports to another
interface to be able to analyze this data stream without disturbing operation.
Note
Mirroring a port does not work beyond switch core boundaries.
Note
You need to disable port mirroring if you want to connect a normal end device to the monitor
port.
