Security and authentication
11.4 IP access control list
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
722 Configuration Manual, 11/2015, C79000-G8976-C252-10
With this command, you configure an IP access control list for the TCP protocol.
You have the following options:
● All incoming and/or outgoing TCP segments are forwarded.
● Incoming and/or outgoing TCP segments of a specific host are forwarded.
● Incoming and/or outgoing TCP segments of hosts of a specific subnet are forwarded.
● Incoming and/or outgoing TCP segments are forwarded to specific ports.
Note
Processing order of the lists
The access control lists are processed on the interface in the order in which they were
created.
The index number of the access control list is not used for this.
You are in the ACL standard configuration mode.
The command prompt is as follows:
cli(config-std-nacl)#
