Siemens SCALANCE XR-500 Configuration Manual

Diagnostics
12.1 Event and fault handling
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
766 Configuration Manual, 11/2015, C79000-G8976-C252-10
Result
You are now in the EVENTS configuration mode.
The command prompt is as follows:
cli(config-events)#
Further notes
You exit the EVENTS configuration mode with the command end or exit.
12.1.5.2
cabletest interface
Description
With this command, you enable the cable test for the specified interface.
Note
Wire pairs
Wire pairs 4
-5 and 7-8 of 10/100 Mbps network cables are not used.
The wire pair assignment
- pin assignment is as follows (DIN 50173):
Pair 1 = pin 1
-2
Pair 2 =
pin 3-6
Pair 3 = pin 4
-5
Pair 4 = pin 7
-8
Requirement
● The interface has no active data traffic.
● You are in the Global configuration mode.
The command prompt is:
cli(config)#
