Layer 3 functions
9.4 VRRPv2 (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
564 Configuration Manual, 11/2015, C79000-G8976-C252-10
Call up the command with the following parameters:
vrrp <vrid(1
-255)> priority <priority(1
-254)> The parameters have the following meaning:
Priority of the virtual router 1 ... 254
Default: 1
The priority of the virtual router is specified.
You configure a VRRP interface with the interface command.
You reset the priority to the default with the
no vrrp priority command.
You assign IPv4 addresses to a virtual router with the
vrrp associated-ip command.
You display the priority with the
show vrrp interface - vrid command.
no vrrp priority
Description
With this command, you reset the router priority back to the default value.
Note
This command is available only with layer 3.
● An IPv4 address is assigned to the virtual router.
● You are in the VRRP Interface configuration mode
.The command prompt is:
cli(config-vrrp-if)#
