Configuration
3.1 System
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
98 Configuration Manual, 11/2015, C79000-G8976-C252-10
You deactivate the interface with the shutdown command.
You can display the status of this function and other information with the
show
interfaces
command.
With this command, you configure the transmission speed of an interface.
The transmission speed can only be configured for electrical data transfer. On optical
connections, the transmission speed is fixed.
● Autonegotiation is disabled.
● You are in the Interface configuration mode of an electrical interface.
The command prompt is as follows:
cli(config-if-$$$)#
Call up the command with the following parameters:
speed {10|100|1000}
The parameters have the following meaning:
Transmission speed 10 Mbps
Transmission speed 100 Mbps
Transmission speed 1000 Mbps
The transmission speed of the interface is configured.
You disable autonegotiation with the no negotiation command.
