Layer 3 functions
9.4 VRRPv2 (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
562 Configuration Manual, 11/2015, C79000-G8976-C252-10
Call up the command with the following parameters:
vrrp <vrid(1-255)> primary-ip <ip_addr>
The parameters have the following meaning:
Value for an IPv4 address Enter a valid IPv4 address.
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 39)".
The primary IPv4 address is specified.
You configure a VRRP interface with the interface command.
You remove the primary IPv4 address with the
no vrrp pirmary-ip command.
You show the configuration of the virtual router with the
show vrrp interface - vrid
command.
no vrrp primary-ip
Description
With this command, you remove an IPv4 address from the virtual router.
Note
This command is available only with layer 3.
You are in the VRRP Interface configuration mode.
The command prompt is as follows:
cli (config-vrrp-if)#
