Network structures
6.3 Spanning Tree
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
217
Call up the command with the following parameters:
show spanning-tree interface
[<interface-type><interface-id>]
layer2-gateway-port
The parameters have the following meaning:
Type or speed of the interface
Enter a valid interface
Module no. and port no. of the interface
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 39)".
The settings for Layer 2 Gateway Port (L2GP) are displayed.
show spanning-tree root
Description
This command shows the settings of the root bridge for the spanning tree function.
You are in the User EXEC mode or in the Privileged EXEC mode.
The command prompt is as follows:
cli> or cli#
