Network structures
6.1 VLAN
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
188 Configuration Manual, 11/2015, C79000-G8976-C252-10
6.1.3.2
no map subnet
Description
With this command, you remove an IPv4 subnet from a VLAN.
Requirement
You are in the Interface configuration mode.
The command prompt is as follows:
cli(config-if-$$$)#
Syntax
Call up the command with the following parameters:
no map subnet <ip-subnet-address>
The parameter has the following meaning:
Parameter
Description
Range of values / note
ip-subnet-address
IPv4 subnet address
Enter a valid subnet address
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 39)".
Result
The IPv4 subnet was removed.
Further notes
You configure the setting with the map subnet command.
You can display the status of this function and other information with the
show subnet-vlan
mapping
command.
6.1.3.3
switchport acceptable-frame-type
Description
With this command, you configure which types of frames are accepted.
Requirement
You are in the Interface configuration mode.
The command prompt is as follows:
cli(config-if-$$$)#
