Layer 3 functions
9.5 VRRPv3 (IPv4 / IPv6)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
582 Configuration Manual, 11/2015, C79000-G8976-C252-10
Call up the command with the following parameters:
vrrp <vrid(1-255)> compatible-mode
The parameter has the following meaning:
The compatibility is enabled.
You enable routing with VRRP3 with the router vrrp3 command.
You assign IP addresses to a virtual router with the
vrrp associated -ip command.
You disable the compatibility with the
no vrrp compatible-mode command.
You can display the status of the function with the
show vrrp3 interface - vrid or with the
show vrrp3 interface command.
no vrrp compatible-mode
Description
With this command, you disable compatibility with VRRPv2. The VRRP router can only send
and receive VRRP packets of version 3.
Note
This command is available only with layer 3.
You are in the VRRP3 Interface configuration mode.
The command prompt is as follows:
cli(config-vrrp-v3-if-$$$)#
