Network structures
6.1 VLAN
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
179
Call up the command with the following parameters:
no interface range vlan <vlan-id(1-4094)> - <vlan-id(2-4094)>
The parameters have the following meaning:
Keyword for a VLAN connection
Number of the addressed VLAN 1 ... 4094
Number of the addressed VLAN
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 39)".
If you address several VLANs, you must insert a blank before and after the hyphen, for
example
no interface range vlan 5 - 10.
The VLANs have been removed from the specified interface area.
With the interface range command, you can put several interfaces or VLANs together to be
able to configure them together.
With this command, you assign a protocol to a protocol group.
You are in the Global configuration mode.
The command prompt is as follows:
cli(config)#
