Layer 3 functions
9.3 OSPFv3 (IPv6)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
513
area range - ipv6prefix/prefix_length
Description
With this command, you assign an area ID an address range. The address range is used to
group the routes within OSPFv3.
Note
This command is available only with layer 3.
● The router is an area border router
● You are in the OSPFv3 router configuration mode.
The command prompt is as follows:
cli(config-ospfv3)#
Call up the command with the following parameters:
area <Area-ID> range
<IPv6-Prefix> / <Prefix-Length>
[{
advertise | not-advertise
}]
[tag <value>] [cost <cost>]
The parameters have the following meaning:
Area ID specify the ID in the IPv4 address
format
x.x.x.x = 0 ... 255
enter a valid IPv6 address
Number of bits belonging to the prefix
1 ... 128 bits
128: The node (host) itself
The address range is advertised outside the ranges. A
summary LSA of type 3 is generated.
-
The address range is not advertised to the outside.
Value that is assigned to the aggregated routes.
Costs for the OSPF interface.
For information on identifiers of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 39)".
